Products.
TURIN Robot
TKB800
TKB800
Category:
Moldel：TKB800 Load：6kg Wingspan：876mm
Model:
TKB800
Payload:
6kg
Arm Reach:
876mm
keyword:
weld
punching press
Hardware polishing
carry
Product Consultation:
Details
Parameter Table
|
Model
|
TKB800
|
|
| Payload | 6kg | |
| Max Working Radius | 876mm | |
| DOF | 4-axis | |
| Body Weight | 26kg | |
| Reducer Brand | enter port | |
| Motor Brand | enter port | |
| Drive Brand | enter port | |
| Rated Power | 1.2kw | |
| Max Speed | J1 | 300°/s |
| J2 | 300°/s | |
| J3 | 320°/s | |
| J4 | 380°/s | |
| Max Operation Area | J1 | ±170° |
| J2 | 135°~-70° | |
| J3 | 255°~-75° | |
| J4 | ±130° | |
| protective specification | IP54 | |
| Position Repeat Accuracy | ±0.08mm | |
| controller | TRC3-A06 | |
| Working Temperature | 0~45℃ | |
Parameter diagram
