Products.
TURIN Robot
TKB6300
TKB6300
Category:
Model ：TKB6300 Load：25kg Wingspan：1700mm
Model:
TKB6300
Payload:
25kg
Arm Reach:
1700mm
keyword:
weld
punching press
Hardware polishing
carry
Product Consultation:
Details
Parameter Table
|
Model
|
TKB6300
|
|
| Payload | 25kg | |
| Max Working Radius | 1700mm | |
| DOF | 6-axis | |
| Body Weight | 280kg | |
| Reducer Brand | enter port | |
| Motor Brand | ItalyRRRobotica | |
| Drive Brand | ItalyRRRobotica | |
| Rated Power | 4.7kw | |
| Max Speed | J1 | 187°/s |
| J2 | 148°/s | |
| J3 | 169°/s | |
| J4 | 234°/s | |
| J5 | 225°/s | |
| J6 | 360°/s | |
| Max Operation Area | J1 | ±160° |
| J2 | 150°~-75° | |
| J3 | 60°~-200° | |
| J4 | ±180° | |
| J5 | ±120° | |
| J6 | ±360° | |
| protective specification | 54 | |
| Position Repeat Accuracy | ±0.08mm | |
| controller | TRC5-B06 | |
| Working Temperature | 0~45℃ | |
Parameter diagram
